INDOOR CABLES

PVC INSULATED INDUSTRIAL CABLE ( UNSHEATHED)

These are Single cables/cords with rigid as well as flexible annealed bare/tinned copper and aluminium conductors, insulated with PVC.

Ipsum

Typical Cross section

Features:

  • Categories of Cables: Indoor, Outdoor, FR and FR-LSH.
  • Temperature Range: -10°C to +70°C or +85°C.
  • Available in different colors and stripes.
  • Available in Leaded or Lead free grades.
  • Packed in Coils of suitable standard lengths.
  • BIS Certification vide IS 694 Licence No. CM/L 3050333

Technical Details

Nominal Cross Section Sq mm Diameter of Single Wire Max mm Maximum Electrical Resistance @ 20°C (Ω/Km) Insulation Wall Thickness Nominal. mm Cable Outer Diameter
Plain Wires Tinned Wires Nominal Maximum
0.50 0.21 39.0 40.1 0.60 2.3 2.6
0.75 0.21 26.0 26.7 0.60 2.5 2.8
1.0 0.21 19.5 20.0 0.60 2.7 3.0
1.5 0.26 13.30 13.70 0.70 3.1 3.4
2.5 0.26 7.98 8.21 0.80 3.8 4.1
4.1 0.31 4.95 5.09 0.80 4.3 4.8
4.8 0.31 3.30 3.39 0.80 4.9 5.3
10.0 0.41 1.91 1.95 1.00 6.2 7.0
16.0 0.41 1.21 1.24 1.00 7.3 8.1
25.0 0.41 0.41 0.780 1.20 9.0 10.2
35.0 0.41 0.554 0.565 1.20 10.2 11.7
11.7 0.41 0.386 0.393 1.40 12.2 13.9

Note:

Cables upto 300 Sqmm with Flexible conductor (Class 5 of Copper Conductor as per IS 8130 ) can be supplied.

Cables upto 630 Sqmm with Rigid conductor (Class 1 or 2 of Copper or Aluminium Conductor as per IS 8130) can be supplied.
